Routing Traffic between Three WireGuard Nodes: Main-Server, Web-Gateway, and Client

Routing Traffic Through Three WireGuard Nodes: Main-Server, Web-Gateway, Client

WireGuard is a modern, fast, and secure VPN that utilizes state-of-the-art cryptography. With its simple and easy-to-use interface, it has become a popular choice for many users. In this article, we will discuss how to route traffic through three WireGuard nodes: Main-Server, Web-Gateway, and Client.

Main-Server

The Main-Server is the primary node that acts as the central hub for all the other nodes. It is responsible for routing traffic between the Web-Gateway and the Client. To set up the Main-Server, you will need to follow these steps:

1. Install WireGuard on the Main-Server
2. Generate a private and public key pair
3. Configure the WireGuard interface
4. Add the Web-Gateway as a peer
5. Start the WireGuard interface

# Install WireGuard
sudo apt install wireguard

# Generate a private and public key pair
umask 077; wg genkey | tee privatekey | wg pubkey > publickey

# Configure the WireGuard interface
cat > /etc/wireguard/wg0.conf < EOF
[Interface]
Address = 10.0.0.1/24
PrivateKey =
ListenPort = 51820

[Peer]
PublicKey =
AllowedIPs = 10.0.1.0/24
Endpoint = :51820
PersistentKeepalive = 25
EOF

# Add the Web-Gateway as a peer
wg set wg0 peer  allowed-ips 10.0.1.0/24 endpoint :51820

# Start the WireGuard interface
systemctl start wg-quick@wg0

Web-Gateway

The Web-Gateway is the second node that acts as a bridge between the Main-Server and the Client. It is responsible for routing traffic between the Main-Server and the Client. To set up the Web-Gateway, you will need to follow these steps:

1. Install WireGuard on the Web-Gateway
2. Generate a private and public key pair
3. Configure the WireGuard interface
4. Add the Main-Server as a peer
5. Add the Client as a peer
6. Start the WireGuard interface

# Install WireGuard
sudo apt install wireguard

# Generate a private and public key pair
umask 077; wg genkey | tee privatekey | wg pubkey > publickey

# Configure the WireGuard interface
cat > /etc/wireguard/wg0.conf < EOF
[Interface]
Address = 10.0.1.1/24
PrivateKey =
ListenPort = 51820

[Peer]
PublicKey =
AllowedIPs = 10.0.0.0/24
Endpoint = :51820
PersistentKeepalive = 25

[Peer]
PublicKey =
AllowedIPs = 10.0.2.0/24
Endpoint = :51820
PersistentKeepalive = 25
EOF

# Add the Main-Server as a peer
wg set wg0 peer  allowed-ips 10.0.0.0/24 endpoint :51820

# Add the Client as a peer
wg set wg0 peer  allowed-ips 10.0.2.0/24 endpoint :51820

# Start the WireGuard interface
systemctl start wg-quick@wg0

Client

The Client is the third node that connects to the Web-Gateway to access the Main-Server. To set up the Client, you will need to follow these steps:

1. Install WireGuard on the Client
2. Generate a private and public key pair
3. Configure the WireGuard interface
4. Add the Web-Gateway as a peer
5. Start the WireGuard interface

# Install WireGuard
sudo apt install wireguard

# Generate a private and public key pair
umask 077; wg genkey | tee privatekey | wg pubkey > publickey

# Configure the WireGuard interface
cat > /etc/wireguard/wg0.conf < EOF
[Interface]
Address = 10.0.2.1/24
PrivateKey =

[Peer]
PublicKey =
AllowedIPs = 0.0.0.0/0
Endpoint = :51820
PersistentKeepalive = 25
EOF

# Add the Web-Gateway as a peer
wg set wg0 peer  allowed-ips 0.0.0.0/0 endpoint :51820

# Start the WireGuard interface
systemctl start wg-quick@wg0

In this article, we have discussed how to route traffic through three WireGuard nodes: Main-Server, Web-Gateway, and Client. The Main-Server acts as the central hub for all the other nodes, while the Web-Gateway acts as a bridge between the Main-Server and the Client. The Client connects to the Web-Gateway to access the Main-Server. By following the steps outlined in this article, you can easily set up a secure and fast VPN using WireGuard.
