Setting up Two Isolated Networks with a ZTE F6600 Router and a Linux Server
In this article, we will discuss the steps required to set up two isolated networks using a ZTE F6600 router and a Linux server. This setup is useful when you want to create separate networks for different purposes, such as a public network and a private network. The Linux server can act as a gateway or a firewall between the two networks.
Prerequisites
- A ZTE F6600 router provided by your ISP
- A Linux server with at least two network interfaces
- Basic knowledge of networking and Linux command line
Setting up the Network
The first step is to configure the ZTE F6600 router to create two separate networks. By default, the router has one network interface that is connected to the internet. We will create a new network interface that is isolated from the internet.
Configuring the ZTE F6600 Router
To configure the ZTE F6600 router, you need to access its web interface. The IP address of the web interface is usually printed on the router itself. Once you have accessed the web interface, you can follow these steps:
- Go to the
Networktab and click onLAN. - Create a new LAN interface by clicking on the
Addbutton. - Set the IP address of the new interface to
192.168.2.1and the subnet mask to255.255.255.0. - Save the changes and apply the new configuration.
Now you have two separate networks, one connected to the internet (192.168.1.x) and one isolated from the internet (192.168.2.x). The next step is to connect the Linux server to both networks.
Connecting the Linux Server
To connect the Linux server to both networks, you need to have at least two network interfaces. One interface should be connected to the isolated network (192.168.2.x) and the other interface should be connected to the internet (192.168.1.x).
Once you have connected the interfaces, you can configure the network settings using the ifconfig command. For example, to configure the isolated network interface, you can use the following command:
ifconfig eth1 192.168.2.100 netmask 255.255.255.0 upReplace eth1 with the name of your network interface. The IP address 192.168.2.100 is an example, you can choose any IP address in the range of 192.168.2.1 to 192.168.2.254.
To configure the internet network interface, you can use the following command:
ifconfig eth0 192.168.1.100 netmask 255.255.255.0 upReplace eth0 with the name of your internet network interface. The IP address 192.168.1.100 is an example, you can choose any IP address in the range of 192.168.1.1 to 192.168.1.254.
Setting up the Firewall
Now that you have two separate networks, you need to set up a firewall to isolate the isolated network from the internet. You can use the Linux server as a firewall by configuring the iptables rules.
Configuring the Firewall
To configure the firewall, you need to allow traffic from the isolated network to the internet and block traffic from the internet to the isolated network. You can use the following iptables commands:
# Allow traffic from the isolated network to the internet
iptables -A FORWARD -i eth1 -o eth0 -j ACCEPT
# Block traffic from the internet to the isolated network
iptables -A FORWARD -i eth0 -o eth1 -j DROP
These commands will allow traffic from the isolated network (eth1) to the internet (eth0) and block traffic from the internet to the isolated network. You can save the iptables rules using the iptables-save command.
In this article, we have discussed the steps required to set up two isolated networks using a ZTE F6600 router and a Linux server. We have covered the following topics:
- Configuring the ZTE F6600 router to create two separate networks
- Connecting the Linux server to both networks
- Setting up the firewall to isolate the isolated network from the internet
