Installing Asus Hyper M.2 Expansion Card with GIGABYTE B450M DS3H and Ryzen 5 3600

Installing Asus Hyper M.2 Expansion Card on GIGABYTE B450M DS3H (Ryzen 5 3600)

In this article, we will provide a detailed guide on how to install the Asus Hyper M.2 expansion card on a GIGABYTE B450M DS3H motherboard with a Ryzen 5 3600 processor. The Asus Hyper M.2 expansion card is an excellent solution for adding more M.2 NVMe SSDs to your system. It supports up to four M.2 NVMe SSDs and provides excellent performance, making it an ideal choice for gamers, content creators, and professionals who require fast storage solutions.

Before You Begin

Before you begin the installation process, ensure that you have the following components:

• Asus Hyper M.2 expansion card
• GIGABYTE B450M DS3H motherboard
• Ryzen 5 3600 processor
• M.2 NVMe SSDs
• Screwdriver

Installing the Asus Hyper M.2 Expansion Card

Follow these steps to install the Asus Hyper M.2 expansion card on your GIGABYTE B450M DS3H motherboard:

1. Shut down your computer and unplug it from the power source.
2. Open the computer case and locate an available PCIe x4 slot on the motherboard.
3. Insert the Asus Hyper M.2 expansion card into the PCIe x4 slot. Ensure that the card is securely seated in the slot.
4. Screw the M.2 SSDs onto the Asus Hyper M.2 expansion card using the provided screws.
5. Connect the SATA power cable to the Asus Hyper M.2 expansion card from the power supply.
6. Close the computer case and plug the computer back into the power source.

Configuring the Asus Hyper M.2 Expansion Card

After installing the Asus Hyper M.2 expansion card, you need to configure it in the BIOS. Follow these steps to configure the Asus Hyper M.2 expansion card:

1. Restart your computer and press the Del key to enter the BIOS.
2. Navigate to the "M.I.T." tab and select "Advanced Frequency Settings."
3. Select "PCIe Speed" and set it to "Gen3."
4. Save the changes and exit the BIOS.

Testing the Asus Hyper M.2 Expansion Card

After installing and configuring the Asus Hyper M.2 expansion card, you need to test it to ensure that it is working correctly. Follow these steps to test the Asus Hyper M.2 expansion card:

1. Restart your computer and enter the Windows operating system.
2. Press the Windows key + X and select "Windows PowerShell (Admin)" or "Command Prompt (Admin)."
3. Type the following command and press Enter: wmic diskdrive get model, mediatype
4. Check the output to ensure that the M.2 NVMe SSDs are listed.

References

• Asus Hyper M.2 x4 Add-in Card User Guide: https://www.asus.com/media/global/files/manual/Motherboards-Manual/Hyper-M2-X4-Add-in-Card-User-Manual.pdf
• GIGABYTE B450M DS3H Motherboard User Manual: https://download.gigabyte.com/FileList/Manual/mb_manual_b450m-ds3h_e.pdf

Note: This article is for informational purposes only. We are not responsible for any damage or harm caused by following the instructions in this article. Always consult the user manual and follow the manufacturer's instructions when installing and configuring hardware components.
