Navigating 8086 CPUs: Bus Handling, Keyboard I/O, Graphics, and Audio
The 8086 microprocessor, introduced in 1978 by Intel, was a significant milestone in the evolution of microprocessors. This 16-bit processor was the first in the x86 architecture lineage, which still powers most desktop and laptop computers today. This article will explore how the 8086 CPU handles buses, keyboard I/O, graphics, and audio, providing a detailed context of the key concepts involved.
Understanding the 8086 CPU Bus Architecture
The 8086 CPU has three buses: the data bus, the address bus, and the control bus. The 16-bit data bus allows the CPU to transfer 16 bits of data at a time, while the 20-bit address bus enables the CPU to address up to 1 MB of memory. The control bus handles the flow of data between the CPU and other peripherals.
MOV AX, 0x1234 ; Move the value 0x1234 to the AX register
MOV DS, AX ; Move the value in AX to the DS segment register
MOV [0x8000], BX ; Move the value in BX to the memory location 0x8000
Keyboard I/O in the 8086 CPU
The 8086 CPU uses the Intel 8255 Programmable Peripheral Interface (PPI) chip to handle keyboard I/O. The 8255 chip has three 8-bit I/O ports: Port A, Port B, and Port C. Port A and Port B are used for input and output, while Port C is used for control.
IN AL, 0x60 ; Read the keyboard data from Port 0x60
TEST AL, 0x01 ; Test if the least significant bit is set
JZ no_key_pressed ; If not, jump to no_key_pressed
; Key has been pressed, handle it here
no_key_pressed:
Graphics and Audio in the 8086 CPU
The 8086 CPU does not have built-in graphics or audio capabilities. Instead, it relies on external peripherals to handle these tasks. For graphics, the most common solution was the CGA (Color Graphics Adapter) card, which provided a maximum resolution of 640x200 pixels with 16 colors. For audio, the PC speaker was the most common solution, which could produce simple tones and beeps.
; Set up the graphics mode
MOV AH, 0x00
MOV AL, 0x03
INT 0x10 ; Call the BIOS video interrupt
; Set up the PC speaker
MOV AH, 0x02
MOV AL, 0xB6 ; Frequency for a 440 Hz tone
OUT 0x43, AL
MOV AL, 0x34
OUT 0x42, AL
MOV AL, 0xC4
OUT 0x42, AL
- The 8086 CPU has a data bus, address bus, and control bus for handling data transfer and communication with peripherals.
- Keyboard I/O is handled using the Intel 8255 Programmable Peripheral Interface (PPI) chip, which has three 8-bit I/O ports.
- Graphics and audio are handled using external peripherals, such as the CGA card for graphics and the PC speaker for audio.
