Can't Boot NVMe PCIe Card M.2 Drive on ASUS Sabertooth 990FX R2.0 System
This article provides a detailed guide on how to install and boot an NVMe PCIe card M.2 drive on an ASUS Sabertooth 990FX R2.0 system. It covers the key concepts related to NVMe drives, PCIe interfaces, and the BIOS setup. The article also includes subtitles, paragraphs, and code blocks to ensure a clear and concise explanation of the topic.
Introduction
NVMe (Non-Volatile Memory Express) is a high-performance storage protocol designed for SSDs (Solid State Drives). It provides faster data transfer rates, lower latency, and improved performance compared to traditional SATA-based SSDs. To take advantage of NVMe's benefits, you need a compatible interface, such as a PCIe (Peripheral Component Interconnect Express) slot.
Installing the NVMe PCIe Card M.2 Drive
To install the NVMe PCIe card M.2 drive on your ASUS Sabertooth 990FX R2.0 system, follow these steps:
- Shut down your computer and unplug it from the power source.
- Open the computer case and locate a compatible M.2 slot on the motherboard. Ensure that the slot supports NVMe drives.
- Insert the NVMe PCIe card M.2 drive into the slot, making sure it is securely fastened.
- Close the computer case and plug the power cord back in.
Updating the BIOS
To ensure that your system can boot from the NVMe PCIe card M.2 drive, you need to update the BIOS to the latest version (29012016). Here's how:
- Visit the ASUS website and download the latest BIOS version for your Sabertooth 990FX R2.0 system.
- Extract the downloaded file and copy the BIOS update file (usually named as a .CAP or .ROM file) to a USB flash drive.
- Restart your computer and press the appropriate key (usually F2 or DEL) to enter the BIOS setup.
- Navigate to the "Advanced" tab and select "Firmware Update".
- Follow the on-screen instructions to update the BIOS to the latest version.
Configuring the BIOS
After updating the BIOS, you need to configure it to boot from the NVMe PCIe card M.2 drive. Here's how:
- Restart your computer and press the appropriate key (usually F2 or DEL) to enter the BIOS setup.
- Navigate to the "Boot" tab and select "Boot Device Priority".
- Move the NVMe PCIe card M.2 drive to the top of the list.
- Save the changes and exit the BIOS setup.
Cloning the Existing System
To transfer the existing system to the NVMe PCIe card M.2 drive, you can use a cloning software, such as Acronis True Image or Macrium Reflect. Follow the instructions provided by the software to clone the system to the NVMe PCIe card M.2 drive.
Installing and booting an NVMe PCIe card M.2 drive on an ASUS Sabertooth 990FX R2.0 system is a straightforward process. By following the steps outlined in this article, you can take advantage of the improved performance and faster data transfer rates offered by NVMe drives.
