Introduction
In this article, we will discuss the issue of being unable to access forwarded devices via VPN, specifically focusing on the device with IP address 10.200.195.70 and subnet 10.200.195.0/24. We will cover the key concepts related to this problem and provide a detailed context to help you understand and resolve the issue.
Understanding the Issue
The problem at hand is related to accessing a device located in a different subnet via a VPN. In this case, the device with IP address 10.200.195.70 is located in the subnet 10.200.195.0/24, and the VPN is connected to the subnet 10.200.200.0/24. The inability to access this device via the VPN can be caused by several factors, such as misconfigured network settings, firewall rules, or routing issues.
Key Concepts
- VPN: A virtual private network (VPN) is a secure connection between two networks over the internet. It allows remote users to access a private network as if they were directly connected to it.
- Subnet: A subnet is a smaller network created within a larger network. It is used to divide a network into smaller segments to improve network performance, security, and management.
- IP Address: An IP address is a unique identifier assigned to each device on a network. It is used to route data packets between devices on the network.
- Firewall: A firewall is a security system that monitors and controls incoming and outgoing network traffic based on predetermined security rules.
- Routing: Routing is the process of selecting a path for data packets to travel from the source to the destination.
Resolving the Issue
To resolve the issue of being unable to access the device with IP address 10.200.195.70 via the VPN, we need to ensure that the network settings, firewall rules, and routing are properly configured. Here are the steps to follow:
Step 1: Check the Network Settings
Check the network settings of the device and the VPN to ensure that they are correctly configured. Make sure that the device is assigned the correct IP address and subnet mask, and that the VPN is connected to the correct subnet.
Device Network Settings:
IP Address: 10.200.195.70
Subnet Mask: 255.255.255.0
VPN Network Settings:
IP Address: 10.200.200.x
Subnet Mask: 255.255.255.0
Connected to: 10.200.195.0/24
Step 2: Check the Firewall Rules
Check the firewall rules on both the device and the VPN to ensure that they allow traffic to flow between the two networks. Make sure that the firewall rules are not blocking any necessary ports or protocols.
Device Firewall Rules:
Allow traffic from: 10.200.200.0/24
Allow traffic to: 10.200.195.0/24
Allow protocol: TCP/UDP
Allow port: 1701, 1723, 500, 4500
VPN Firewall Rules:
Allow traffic from: 10.200.195.0/24
Allow traffic to: 10.200.200.0/24
Allow protocol: TCP/UDP
Allow port: 1701, 1723, 500, 4500
Step 3: Check the Routing
Check the routing table on both the device and the VPN to ensure that they have the correct routes to reach each other. Make sure that the routing table includes a route to the subnet 10.200.195.0/24 via the VPN interface.
Device Routing Table:
Destination Gateway Genmask Flags Metric Ref Use Iface
10.200.195.0 * 255.255.255.0 U 100 0 0 eth0
default 10.200.200.1 0.0.0.0 UG 100 0 0 tun0
VPN Routing Table:
Destination Gateway Genmask Flags Metric Ref Use Iface
10.200.195.0 * 255.255.255.0 U 100 0 0 tun0
default 10.200.200.1 0.0.0.0 UG 100 0 0 eth0
In this article, we have discussed the issue of being unable to access forwarded devices via VPN, specifically focusing on the device with IP address 10.200.195.70 and subnet 10.200.195.0/24. We have covered the key concepts related to this problem and provided a detailed context to help you understand and resolve the issue. By following the steps outlined in this article, you should be able to access the device via the VPN and resolve any connectivity issues.
