Angular MatBottomSheet Causes Background Image Shift Issue

Are you experiencing an issue with your background image shifting when you use the Angular MatBottomSheet component? Don't worry, you're not alone. This is a common issue that many Angular developers face. In this article, we'll explain what causes this issue and how to fix it.

What is Angular MatBottomSheet?

Angular Material is a popular UI component library for Angular applications. It provides a set of pre-built components that you can use to quickly build a beautiful and responsive user interface. One of the components that Angular Material provides is the MatBottomSheet.

The MatBottomSheet is a modal dialog that slides up from the bottom of the screen. It's commonly used to display a list of options or settings that the user can choose from. It's a great way to add additional functionality to your application without cluttering the user interface.

What Causes the Background Image Shift Issue?

When you use the MatBottomSheet, you might notice that your background image shifts upwards. This is because the MatBottomSheet is positioned above the content of your page, which causes the content to shift upwards to make room for the MatBottomSheet. This can be frustrating, especially if you have a carefully designed background image that you don't want to be disturbed.

The reason for this issue is that the MatBottomSheet is not part of the normal document flow. When you add a MatBottomSheet to your page, it's added to the body of the document, which is outside of the normal document flow. This means that the MatBottomSheet doesn't take up any space in the document, which can cause the background image to shift.

How to Fix the Background Image Shift Issue

Fortunately, there's an easy fix for this issue. All you need to do is add a container element around your content and set the height of the container to 100%. This will ensure that your content takes up the full height of the viewport, even when the MatBottomSheet is displayed.

<div class="container">
  <div class="content">
    <!-- Your content goes here -->
  </div>
  <button mat-raised-button (click)="openBottomSheet()">Open Bottom Sheet</button>
</div>

In this example, we've added a container element with a class of "container". We've also added a content element with a class of "content" to hold our content. Finally, we've added a button that opens the MatBottomSheet when clicked.

Next, we'll add some CSS to set the height of the container element to 100%:

.container {
  height: 100%;
  display: flex;
  flex-direction: column;
}

.content {
  flex-grow: 1;
  overflow-y: auto;
}

In this CSS, we've set the height of the container element to 100% and set the display property to flex. We've also added a flex-direction property to make the container element a column. This will ensure that the content element takes up the full height of the container.

Finally, we've added a flex-grow property to the content element to make it take up the full height of the container. We've also added an overflow-y property to add a scrollbar to the content element if the content is too long to fit in the viewport.

The background image shift issue that occurs when using the Angular MatBottomSheet component can be frustrating, but it's easy to fix. By adding a container element around your content and setting the height of the container to 100%, you can ensure that your content takes up the full height of the viewport, even when the MatBottomSheet is displayed.
