Getting the MFT Entry by the Record ID in $DATA Attribute List on NTFS

Getting the MFT Entry by the Record ID in $DATA Attribute List on NTFS

NTFS (New Technology File System) is a file system used by Windows operating systems. It provides advanced features like file and folder permissions, encryption, and compression. The Master File Table (MFT) is a crucial component of NTFS, which stores information about all files and directories on a disk.

Each file or directory in NTFS has a unique identifier called a Record ID. This ID allows the operating system to locate and access the corresponding MFT entry for that file or directory. In this article, we will explore how to retrieve the MFT entry using the Record ID in the $DATA attribute list.

Understanding the $DATA Attribute List

The $DATA attribute list is a part of the MFT entry for a file or directory. It contains various attributes associated with the file, such as the file size, timestamps, and data content. The $DATA attribute is responsible for storing the actual data of the file or directory.

Within the $DATA attribute, the data is divided into multiple data runs. Each data run represents a contiguous block of data on the disk. These data runs allow efficient storage and retrieval of large files by utilizing non-contiguous disk space.

Locating the MFT Entry by Record ID

To retrieve the MFT entry using the Record ID, we need to perform the following steps:

1. Open the NTFS volume where the file or directory is located.
2. Read the $MFT file, which contains the MFT entries for all files and directories on the volume.
3. Search for the MFT entry corresponding to the Record ID.
4. Within the MFT entry, locate the $DATA attribute list.
5. Parse the $DATA attribute list to extract the desired data runs.
6. Read the data runs from the disk to retrieve the actual data of the file or directory.

By following these steps, we can obtain the MFT entry for a specific file or directory using its Record ID.

Example Code

Here is an example code snippet in C++ that demonstrates how to retrieve the MFT entry by the Record ID:

#include <windows.h>
#include <stdio.h>

int main()
{
    const DWORDLONG recordID = 12345; // Replace with the desired Record ID
    const WCHAR* volumePath = L"C:\\"; // Replace with the path to the NTFS volume

    HANDLE volumeHandle = CreateFile(volumePath, GENERIC_READ, FILE_SHARE_READ, NULL, OPEN_EXISTING, FILE_ATTRIBUTE_NORMAL, NULL);
    if (volumeHandle == INVALID_HANDLE_VALUE)
    {
        printf("Failed to open the volume.
");
        return 1;
    }

    FILE_RECORD_INPUT_BUFFER inputBuffer;
    inputBuffer.FileReferenceNumber.QuadPart = recordID;

    FILE_RECORD_OUTPUT_BUFFER outputBuffer;
    DWORD bytesReturned;

    BOOL result = DeviceIoControl(volumeHandle, FSCTL_GET_NTFS_FILE_RECORD, &inputBuffer, sizeof(inputBuffer), &outputBuffer, sizeof(outputBuffer), &bytesReturned, NULL);
    if (!result)
    {
        printf("Failed to retrieve the MFT entry.
");
        CloseHandle(volumeHandle);
        return 1;
    }

    // Process the MFT entry and extract the desired information

    CloseHandle(volumeHandle);
    return 0;
}


In this code, we use the DeviceIoControl function with the FSCTL_GET_NTFS_FILE_RECORD control code to retrieve the MFT entry for the specified Record ID. The outputBuffer structure contains the MFT entry data, which can be further processed as per the requirements.

Understanding how to retrieve the MFT entry by the Record ID in the $DATA attribute list is essential for various file system-related operations. By following the steps mentioned in this article and utilizing appropriate system APIs, you can access the necessary information stored in the MFT entry for a specific file or directory on an NTFS volume.
